Session 4: Running a project

Here you will learn several concepts needed for running real projects:

• use one screen session per project (if you’re juggling more projects)

• keep your code in a text file (using nano text editor)

• keep your data files separate from your code

• make your intent more legible by wrapping code in functions and script files

• write handy scripts in awk

• do the same thing with many files at once

• speed up your processing by parallelizing the work

Keep your stuff ordered

Let’s pretend we’re starting to work on something serious, a new project:

cd ~/projects

# a new project dir, separate dir for data in one shot
mkdir -p unix-advanced/data

# set your work dir to the 'current' project dir
cd unix-advanced

# definitely run screen to be safe
# screen sessions can be named, which helps you
screen -S advanced

# prepare source data
cp /data-shared/bed_examples/Ensembl.NCBIM37.67.bed data/

# add a new window with ctrl+a c

# note and save all the (working) code
nano workflow.sh

Note

The nano bottom bar has a lot of weird symbols. ^O means type ctrl-o, pressing both of the keys at once. M-U means alt-u, again pressing both simultaneously. For some reason, Write Out means Save in usual parlance.

To edit a file on the remote machine, you have to use a text editor on that machine. One of the most basic editors is nano.

You’ll be using screen to keep two windows open at once. In the first window, you’ll be experimenting with shell commands. In the second one, you’ll keep track of the final versions of your commands, that comprise your workflow.

That is - after you’re satisfied with your command at the bash prompt, copy it to the second window where you have nano open, and hit ctrl-o to save it.

You’ll be writing code on your own now, so you need to keep track of what you created. I’ll occasionally post solutions to Slack.

awk (pronounced [auk])

awk is most often used instead of cut, when the fields are separated by spaces (not tabulators) and padded to a fixed width. awk can ignore the whitespace.

awk also allows you to reorder the columns. cut can’t do this:

Hands on!

# test the smart <tab> auto-complete!
INPUT=data/Ensembl.NCBIM37.67.bed

# $INPUT contains some genome annotations
# look around the file a bit
# - there are chromosome ids in the first column
# - we want to count the annotations per each chromosome

<$INPUT cut -f # complete the rest!!

But what if you wanted to have a table which mentions chromosomes first and then the counts? Enter awk. Every line (called record) is split into fields, which are assigned to variables $1 for first field, $2 for second etc. The whole line is in $0 if needed. awk expects the program as first argument:

Hands on!

# note the single quotes, they're important because of $
your_code_here | awk '{print $2, $1}'

Additionally you can add conditions when the code is executed:

Hands on!

your_code_here | awk '($2 < 10) {print $2, $1}'

Or even leave out the code body, which is the same as one {print $0} statement - that is print the matching lines:

Hands on!

your_code_here | awk '($2 < 10)'

There are some other variables pre-filled for each line, like record number NR (starting at 1) and number of fields NF.

# NF comes handy when checking if it's okay to
# process a file with (say) cut
<$INPUT awk '{print NF}' | uniq

Let’s play with some fastq files. Extract first five files to data. We’ll explain how xargs works later:

INPUT=/data-shared/fastq/fastq.tar.gz
<$INPUT tar tz | head -5 | xargs tar xvf $INPUT -C data

Look at the data with less - these are reads from 454, with varying read lengths. Let’s check the lengths:

<data/HRTMUOC01.RL12.01.fastq paste - - - - | awk '{print $1, length($2)}' | head

What paste does here is it takes four lines from the input and puts them side by side, separated by \t characters (and repeats for the rest of the input).

Let’s filter on the sequence length, keeping only reads longer than 100 bases. We’d like to output a valid fastq file (that means reversing the paste operation):

Hands on!

<data/HRTMUOC01.RL12.01.fastq paste - - - - | # can you figure out?

#  if we replaced all the \t with \n (hint: tr)

What have we learned?

• use awk when cut falls short

• use awk to filter rows based on field values

• use awk to create summary tables

Functions in the Shell

This creates a command called uniqt that will behave as uniq -c, but there will be no padding (spaces) in front of the numbers, and numbers will be separated by <tab>, so you can use it with cut.

uniqt() { uniq -c | sed -r 's/^ *([0-9]+) /\1\t/' ;}

Now test it:

<data/Ensembl.NCBIM37.67.bed cut -f1 | sort | uniqt | head

You can see that the basics of the syntax are your-name() { command pipeline ;}. If you want to pass some arguments into the function, use $1, $2 etc.:

test-function() { echo First argument: $1 ;}
test-function my-argument

When not given any inputs, the command behaves in the ‘unix way’ - it reads from stdin and writes to stdout.

Now create a function called fastq-min-length, with one argument (use $1 in the body of the function) giving the minimal length:

Hands on!

fastq-min-length() { paste - - - - | your_code_here ;}

# which will be used like this:
<data/HRTMUOC01.RL12.01.fastq fastq-min-length 90 > data/filtered.fastq

There is a problem with quoting. Awk uses $1 for something else than the shell, we need to protect $1 with single quotes, but we still need to access shell’s $1 somehow… Awk’s -v argument helps in this case - use it like awk -v min_len=$1 '(length($2) > min_len)'.

Note

Let’s pop-open the matryoshka. What is terminal, what is a shell, what is Bash?

The program which takes care of collecting your keystrokes and rendering the colored characters which come from the server is called a terminal. Famous terminals are mintty (that’s what you’re using in Windows now), Konsole, Terminal App… The next doll inside is ssh. It takes care of encrypted communication with the remote server. An interesting alternative for geeks is mosh (google it yourself;). Now you need a program to talk to on the remote side - that is the shell. We’re using bash now, sometimes you can meet the simpler cousin sh, and the kool kids are doing zsh. To recap, Bash is to shell what Firefox is to browser.

What have we learned?

• use function_name() { your_code_here ;} to create a function

• use $1, $2 etc. to access arguments you pass on the command line

• use -v to pass arguments to awk to resolve quoting issues

Shell Scripts

Another way to organize your code is to put it into a separate file called a ‘script file’. It begins with a shebang line, telling the computer which language is the script in. Bash shebang is #! /bin/bash. Take care to give a descriptive name to your script:

nano fastq-filter-length.sh

Copy and paste the following code block into the nano editor, save it with ctrl+o and switch to another bash window in screen.

Hands on!

#!/bin/bash

# your_code_here

echo Replace me with real code!
echo Arguments: $1 $2

# to stay with the 'tool concept'
# expect input on stdin and output the results to stdout

We need to mark the file as executable and test it:

chmod +x fastq-filter-length.sh

# check with ls, filter_fastq.sh should be green now
# and using ll you should see the 'x' (eXecutable) permission
ls
ll

# and run it (the ./ is important!)
./fastq-filter-length.sh

Note

You can check file permissions by typing ll instead of ls. rwx stand for Read, Write, eXecute, and are repeated three times, for User, Group, and Others. The two names you see next to the permissions are file’s owner user and group.

You can change the permissions - if you have the permission to do so - by e.g. chmod go+w - “add write permission to group and others”.

Now collect your code from above (contents of your function, not the whole function) and paste it below the shebang. Don’t forget to remove the debug echo parts - otherwise your script will spoil it’s output with some useless chatter.

# when the final code is there, you need to give it input (and maybe save the output):
<data/HRTMUOC01.RL12.01.fastq ./fastq-filter-length.sh 90 > data/filtered.fastq

What have we learned?

• save your code in a reusable file that you can run from the command line

• use shebang line and chmod +x to make your script executable

• use $1, $2 etc. to access arguments you pass on the command line

Process multiple files

Multi-file processing is best done with find and xargs.

Let’s check the basic concepts - find converts directory structure to ‘data’ (stdout), xargs converts stdin to command line(s).

# Investigate!

find data -type f

# here xargs appends all the lines from stdin to the command
find data -type f | xargs echo

# here xargs replaces the {} with the line from stdin
# and when there are more lines, it runs the command multiple times
find data -type f | xargs -I{} echo File: {} found!

There is a lot of filtering options built-in to find. You can filter files, directories, by name, size, modification time, and more. Check man find for details.

If there are spaces or more ‘weird’ characters in the file names, you have to add -print0 to the end of the find command and use xargs -0 to read the \0 separated arguments.

Hands on!

# we won't see the problem by using echo, let's use cat to display the data instead

# create a problematic file
mkdir data2
echo 'Contents of my data file' > 'data2/problematic file name.txt'

# this won't work!
# Explain why?
find data2 -type f | xargs cat

# improve the above command to work with spaces in file names

# your_code_here

# the output has to be the same as
cat 'data2/problematic file name.txt'

You can also replace basic bash loops with xargs:

# Investigate!

for i in {1..10}; do echo $i; done

# here xargs replaces the {} with the line from stdin
# and when there are more lines, it runs the command multiple times
seq 1 10 | xargs -I{} echo {}

# here xargs appends all the lines from stdin to the command
seq 1 10 | xargs echo

What have we learned?

• use find to list files in a directory tree

• use xargs to convert stdin to command line arguments

• if your filenames contain spaces, use -print0 and -0 to use \0 as separator

• use -I{} to run the command multiple times with different arguments

• use seq to replace bash loops

Scale up to multiple cores

parallel is a substitute to xargs. The primary difference is that by default parallel runs one instance of the command per each CPU core on your machine. Modern machines do have four and more CPU cores.

Additional parallel has a ‘nicer’ and more powerful syntax.

Do control the number of jobs (-j) only when sharing the machine with someone, or when you’re sure that your task is IO bound. Otherwise parallel does a good job choosing the number of tasks to run for you.

Note

Parallelizing things IS difficult. There’s no discussion about that. There are some rules of thumb, which can help - but if you want to squeeze out the maximum performance from your machine, it’s still a lot of ‘try - monitor performance - try again’ cycles.

To get good performance it is important to know what happens during data processing: First the data is loaded from hard drive to memory, then from memory to the CPU, the CPU does the calculation, then the results have to get to the memory and saved to the hard drive again. Different workloads take different amounts of time in each step.

In general, you need a work unit which takes much longer to calculate than it takes to load the data from the hard drive (compare times of pv data > /dev/null to pv data | your-task > /dev/null), usually a good work unit takes on the order of minutes. When disk access seems to be the limiting factor, you can try to compress the data with some fast compressor like lz4. Do not parallelize disk intensive tasks, it will make things only slower! If you still want to use parallel’s syntax, use parallel -j1 to use only single core.

The most powerful thing about parallel is it’s substitution strings like {.}, {/}, {#} - check man parallel.

parallel echo Ahoj ::: A B C

parallel --dry-run echo Ahoj ::: A B C

parallel echo File: {} found! ::: data/*.fastq

parallel echo File: {/} found! ::: data/*.fastq

parallel echo File: {/.} found! ::: data/*.fastq

Note

If your data is a single file, but the processing of one line is not dependent on the other lines, you can use the split command to create several files each with defined number of lines from the original file.

What have we learned?

• use parallel to run the same command for multiple files

• use -j to control the number of simultaneous jobs

• use {} to access the input arguments

• use {.}, {/}, {#} to access parts of the input arguments
